VaproShield WRB's

VaproShield manufactures high-performance, vapor permeable, water resistive barriers (WRB) and air barrier (AB) membranes. Their WrapShield SA membrane is the only primerless self-adhering membrane and the first on the market to obtain a DECLARE label. Like a nutrition label for building products, DECLARE labels list all the materials found in a given product. WrapShield SA is free of Red List chemicals.

Why VaproShield Membranes for WRB?

  • ABAA Approved & ASTM E2357 compliant assemblies

  • Vapor permeable, Air and Water barriers allow building components to "dry out" as best building practice.

  • Primerless, Self-Adhering and integrated tape systems for faster installation

  • Straightforward two-component systems include feasible window and door rough opening details

  • Open & Closed Rainscreen options

  • Numerous NFPA 285 Compliant Assemblies

Chapter 4, 2015 IECC - Air Barriers for Commercial Energy Efficiency

Assemblies of materials and components: Must have an average air leakage not to exceed 0.04 cfm/ft.2 under a pressure differential of 0.3 in. w.g. (1.57 psf) when tested in accordance with ASTM E 2357.



WrapShield SA

  • Fully Self-Adhered, water resistive, vapor permeable air barrier sheet membrane

  • Does not require primer on any surface

  • DECLARE label - red list free!

  • 6 month UV and climate exposure

  • High Temperature Resistance - great behind metal panels

  • Class A Fire Rating < 25 ASTM E84 Flame Spread

  • Passes ASTM E2357 and is ABAA approved as Air Barrier

  • 20 year warranty

  • DATA SHEET

  • SPECS

RevealShield SA

  • Long-term UV Stability behind open-joint rainscreen systems. Black and without a label, this vapor permeable self-adhered air barrier peel & stick membrane is designed for exposure

  • Does not require primer on any surface

  • Exceptional UV stability - up to 40% open rain screen

  • Zero VOC's

  • Class A Fire Rated - Flame Spread Index 0

  • Passes ASTM E2357 and is ABAA approved as Air Barrier

  • 20 year warranty

  • DATA SHEET

  • SPECS

WrapShield IT

  • Mechanically attached, water resisitive vapor permeable air barrier with integrated tape at the horizontal seams

  • All season, all weather installation

  • Sustains up to 6 month UV and climate exposure

  • Air Barrier Assembly Test ASTM E2357 passed

  • Fire Rated Class A < 25 Flame Spread ASTM E84

  • Fully Tested Air Barrier Assembly

  • 20 year warranty

  • DATA SHEET

  • SPECS

WrapShield RS Rain Screen

  • A mechanically attached, water resistive (WRB) vapor permeable air barrier (AB) membrane with built-in screen drainage matrix and integrated tape at horizontal seams

  • Built in 3mm, 7mm, 11mm drainage matrix options

  • Creates unimpeded vertical drainage plane behind cladding

  • All season, all weather installation

  • 20 year warranty

  • DATA SHEET

  • SPECS

VaproShield Accessories

RevealShield IT

  • A UV stable, black, mechanically attached water resistive vapor permeable air barrier with integrated tape.

  • Use with open joint cladding systems - up to 40% open wall area. Use with joints up to 2" wide

  • All season, all weather installation

  • Air Barrier Assembly Test ASTM E2357 passed

  • Fire Rated Class A < 25 Flame Spread ASTM E84

  • 20 year warranty

  • DATA SHEET

  • SPECS

SlopeShield SA - roofing underlayment

  • A fully self-adhered water resistive vapor permeable air barrier roof underlayment

  • Does not require a primer

  • Vapor Permeance - 50+ perm rating

  • Zero VOC, Class A Fire Rating < 25 Flame Spread

  • High Temperature Resistance

  • Tough, Durable, Tear Resistant

  • Cinches around fasteners

  • 20 year warranty

  • DATA SHEET

  • SPECS
